| ITA HOOK FORKS CLASS 2A | |||
| Capacity @ 24" or 600mm Load Center | Fork Size - Inches | Fork Size - Millimeters | Fork Length |
| 4,000 lbs./Pair 1,800 kgs./Pair |
1.25 x 4 | 100 x 35 | Lengths from 36"-96" or customized lengths |
| 5,500 lbs./Pair 2,500 kgs./Pair |
1.5 x 4 | 100 x 40 | |
| 6,600 lbs./Pair 3,000 kgs./Pair |
1.75 x 4 | 100 x 45 | |
| 6,600 lbs./Pair 3,000 kgs./Pair |
1.5 x 4.75 | 120 x 40 | |
| 6,820 lbs./Pair 3,100 kgs./Pair |
1.5 x 5 | 125 x 40 | |
| ITA HOOK FORKS CLASS 3A | |||
| Capacity @ 24" or 600mm Load Center | Fork Size - Inches | Fork Size - Millimeters | Fork Length |
| 6,600 lbs./Pair 3,000 kgs./Pair |
1.75 x 4 | 100 x 45 | Lengths from 36"-96" or customized lengths |
| 6,600 lbs./Pair 3,000 kgs./Pair |
1.5 x 5 | 125 x 40 | |
| 8,250 lbs./Pair 3,750 kgs./Pair |
1.75 x 5 | 125 x 45 | |
| 8,400 lbs./Pair 3,800 kgs./Pair |
2 x 4 | 100 x 50 | |
| 8,400 lbs./Pair 3,800 kgs./Pair |
1.75 x 4.75 | 120 x 45 | |
| 10,032 lbs./Pair 4,560 kgs./Pair |
2 x 4.75 | 120 x 50 | |
| 10,200 lbs./Pair 4,700 kgs./Pair |
2 x 5 | 125x 50 | |
| 12,600 lbs./Pair 5,800 kgs./Pair |
2 x 6 | 150x 50 | |
| ITA HOOK FORKS CLASS 4A | |||
| Capacity @ 24" or 600mm Load Center | Fork Size - Inches | Fork Size - Millimeters | Fork Length |
| 17,600 lbs./Pair 8,000 kgs./Pair |
2.25 x 6 | 150 x 60 | Lengths from 36"-96" or customized lengths |
| 19,800 lbs./Pair 9,000 kgs./Pair |
2.5 x 6 | 150 x 65 | |
| 22,000 lbs./Pair 10,000 kgs./Pair |
2.75 x 6 | 150 x 70 | |
| 26,400 lbs./Pair 12,000 kgs./Pair |
3 x 6 | 150 x 75 | |
